Input                          Main circuit power supply: AC230V、400V, 50/60Hz

                                  Control power supply: AC110~240V, 15W, 50/60Hz

Output                       Rated voltage: 0 ~ 98% of the main circuit power supply   voltage (phase shift control)

                                  Rated current: 25~450A

Control                      Operation mode: phase shift trigger, power regulation and  fixed period, power regulation and

characteristic             Control mode: α、U、I、P

                                   Load property: resistive load, inductive load

Performance index     Control accuracy: 1%                                                      Stability: ≤0.2%

Interface description   Analog input: 1 way DC 4 ~ 20mA, 1 way DC0 ~ 5V / 0 ~ 10V

                                   Switch input: 1NO operation allowed (passive)
                                   Switch output: 1NO fault state output (passive)

                                   Communication: Standard RS485 communication interface, supporting Modbus RTU communication;Profibus-

                                                             DP and Profinet communication gateway can be selected;
                                   Protection functions: abnormal power supply protection, overcurrent protection and overheating protection

   Note: the product continues to innovate and the performance continues to improve. This parameter description is for reference only.
